Model Number : NI-LBO
HSN CODE : 85141000
- Double wall construction with Inner chamber made of Stainless Steel – 304 Grade
- Exterior of CRCA steel with powder coat finish.
- High density glass wool insulation between walls to prevent heat dissipation.
- Heating elements are made of high-grade Nichrome wire and placed at the bottom.
- Temperature Range: 5°C above ambient to 250°C
- Temperature controlled by Capillary Thermostat with +/- 2°C Accuracy.
- Gravity convection & Shelves are made of Galvanized wire mesh.
- Operates on 230 Volts AC Single phase 50 Hz.
|
MODEL |
WORKING SPACE (W x D x H) |
CAPACITY |
WATTS |
SHELVES |
|
NI-LBO-01 |
12 X 12 X 12 Inch (30 X 30 X 30) CM |
27 LTRS |
750 |
1 NO. |
|
NI-LBO-02 |
14 X 14 X 14 INCH (35 X 35 X 35) CM |
45 LTRS |
1000 |
2 NOS. |
|
NI-LBO-03 |
18 X 18 X 18 INCH (45 X 45 X 45) CM |
90 LTRS |
1500 |
3 NOS. |
|
NI-LBO-04 |
18 X 18 X 24 INCH (45 X 45 X 60) CM |
120 LTRS |
2000 |
3 NOS. |
|
NI-LBO-05 |
24 X 24 X 24 INCH (60 X 60 X 60) CM |
220 LTRS |
2500 |
3 NOS. |
|
NI-LBO-06 |
24 X 18 X 36 INCH (60 X 45 X 90) CM |
250 LTRS |
2500 |
3 NOS. |
|
NI-LBO-07 |
24 X 24 X 36 INCH (60 X 60 X 90) CM |
325 LTRS |
3000 |
4 NOS. |
OPTIONAL ACCESSORIES FOR BOTTOM HTR TYPE OVEN & INCUBATOR:
A. Dual display Microprocessor based PID Temperature Controller
B. Air circulation by Motorized blower
C. PID Temperature Controller with timer of 999 minutes
