Model Number : NI-VLF
HSN CODE : 84192090
Ideal for Microbiological Manipulations, Sterility Testing, research work & for general dry-processing work in semiconductor industry etc.
- Construction : Standard : Full Cabinet made from CRCA Steel Sheet - Powder coat finished.
GMP : Full Cabinet made from Stainless Steel (304 Grade). - Working Table Top : Made from Stainless Steel (304 Grade).
- Side panels : Thick transparent Acrylic.
- Motor Mounting : Unique spring suspension system with bellow which helps to reduce Vibration and noise.
- HEPA Filter : Mini Pleat - High Efficiency Particular Air Filter with Efficiency 99.97% down on 0.3 micron.
- Pre-Filter : Washable Filter having efficiency of 95 % down to 5 microns.
- Air Flow Velocity : 90 FPM (0.45 m/s) 10 FPM (0.05 m/s) average velocity measured 6 in.(153.4 mm) from the diffuser screen. Uniformity 20% of average or better.
- Air Circulation : Balanced blowers fitted with direct driven FHP Motor.
(For Variable air flow speed in accordance with filter loading) - Static Pressure Indicator : Oil Filled Manometer
- Inner chamber Sterilization : Through UV Germicidal tube.
- Inner chamber Illumination : Fluorescent tube light
- Noise Level : < 65 DB measured at 1 Mtr from filter face.
- Gas Cock Provision.
- Castor Wheel for movability.
|
MODEL |
WORKING AREA (L x W x H) |
HEPA FILTER DIMENSIONS |
PRE-FILTER |
ILLUMINATION |
|
NI-VLF-01 |
2 X 2 X 2 Ft |
24” x 24” x 6” |
1 NO. |
1 X 20 WATTS |
|
NI-VLF-02 |
3 X 2 X 2 Ft |
36” x 24” x 6” |
1 NO. |
1 X 20 WATTS |
|
NI-VLF-03 |
4 X 2 X 2 Ft |
48” x 24” x 6” |
1 NO. |
1 X 40 WATTS |
|
NI-VLF-01 |
2 X 2 X 2 Ft |
24” x 24” x 6” |
1 NO. |
1 X 20 WATTS |
|
NI-VLF-02 |
3 X 2 X 2 Ft |
36” x 24” x 6” |
1 NO. |
1 X 20 WATTS |
|
NI-VLF-03 |
4 X 2 X 2 Ft |
48” x 24” x 6” |
1 NO. |
1 X 40 WATTS |
