Model Number :Â NI-LTB
HSN CODE :Â 84191920
- These heating cooling baths are ideal for both immersing samples & circulating controlled temperature liquid to external equipment’s.
- Double walled in construction, Inner leak proof argon welded tank made of stainless steel – 304 grade & Exterior of CRCA steel with powder coat finish.
- Interior made of Stainless Steel – 316 grade and Exterior of Stainless Steel 304 grade matt finish in all GMP MODELS.
- The high grade PUF (Polyurethane Foam) insulation is provided to minimize the heat exchange.
- Heating is by specially designed heaters S.S. Tubular immersion heaters.
- Cooling is done by CFC free hermetically sealed Emerson Copland make compressors utilizing R-134 A an eco-friendly refrigerant.
- Pump cum stirring assembly for internal & external recirculation.
- Drainage at the side of the bath is provided as outlet.
- Temperature controlled by Dual Display Microprocessor based PID Temperature Controller & Pt – 100 Sensors.
- Temperature Range: 0°C TO 100°C.
- Temperature Accuracy: ± 0.5 °C.
- Temperature Resolution: 0.1°C.
- Operates on 230 Volts AC Single Phase 50 Hz.
|
MODEL |
WORKING SPACE (L x W x D) |
CAPACITY (LTRS) |
|
NI-LTB-01 |
25 X 20 X 20 CM |
15 |
|
NI-LTB-02 |
30 X 25 X 25 CM |
30 |
Â
GMP models are also available. (P.O.R.)
